Transfer Case for Wheeled Vehicles ZQC500
Model: ZQC500
Ratio (On-road/Off-road): 0.91/2.08
Max Input Torque: 5000 Nm
Max Input Speed: 4300 rpm
DuraMac Transfer Case
As a high-tech leader in the drivetrain sector, DuraMac has long focused on the R&D and manufacturing of transmission units, transfer cases, planetary gearboxes, and powertrains for new energy vehicles, backed by robust large-scale production capabilities. DuraMac has established a comprehensive technological innovation system and strictly implements a quality management system certified to ISO 9001 and IATF 16949 standards, ensuring product reliability and consistency throughout the entire production process. Through continuous technological innovation and exceptional product quality, its offerings are widely adopted across multiple industrial sectors, earning high trust and acclaim from both the market and customers.
DuraMac
DCEC ISL8.9 series automotive engine is four-strokes engine with 114 mm bore and 145 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 270 HP to 400 HP.
Fast Gear
The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.
EV Truck
Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.
DANA Axle
Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.
Datong Gear
The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
All Wheel Drive Off-road Chassis
Dongfeng Special Vehicle's all-wheel-drive off-road chassis series, developed based on military technology platforms, supports 4×4/6×6 drive configurations and delivers exceptional cross-country capability, high reliability, and strong environmental adaptability. DuraMac provides customized off-road solutions, with products widely applied in high-altitude rescue, wilderness exploration, special transport, and military applications, meeting the demands of both domestic and international specialty vehicle markets.
Medium & Heavy-duty Truck
DuraMac offers a full range of Dongfeng solutions for medium-to-heavy-duty trucks, covering diesel, pure electric, and hydrogen fuel cell powertrains. Its pure electric trucks feature high-energy-density batteries and electric drive systems with dual-gun fast charging capability, ensuring high operational efficiency. Hydrogen-powered heavy-duty trucks are equipped with an intelligent VCU control system and offer multiple power variants. All products utilize high-strength chassis and IP68-rated electrical systems, meeting diverse operational demands across engineering transport, port logistics, and urban distribution.
Find Transfer Cases by Series
This is the list of all DuraMac Transfer Case series for automotive, off‑road, industrial, construction machinery and special vehicle applications. Click here to find transfer case by type
Wheeled Vehicle Transfer Cases
- DURAMAC Wheeled Vehicle Transfer Cases Series Chart
- DURAMAC Wheeled Vehicle Transfer Cases Series Catalogue
| DURAMAC Wheeled Vehicle Transfer Cases Series Catalogue | ||||||||
ZQC600
wheeled vehicle transfer case ZQC600
Model: ZQC600
Ratio (On-road/Off-road): 0.95/2.12
Max Input Power/Torque: 5000 Nm
Max Input Speed: 4300 rpm
ZQC800
wheeled vehicle transfer case ZQC800
Model: ZQC800
Ratio (On-road/Off-road): 1/1.5
Max Input Power/Torque: 8000 NM
Max Input Speed: 3000 rpm
ZQC1200
wheeled vehicle transfer case ZQC1200
Model: ZQC1200
Ratio (On-road/Off-road): 1/1.75or1.285
Max Input Power/Torque: 12000 NM
Max Input Speed: 3000 rpm
ZQC1600
Transfer Case for Wheeled Vehicles ZQC1600
Model: ZQC1600
Ratio (On-road/Off-road): 0.89/1.536
Max Input Power/Torque: 18000 NM
Max Input Speed: 2800 rpm
ZQC2000
wheeled vehicle transfer case ZQC2000
Model: ZQC2000
Ratio (On-road/Off-road): 0.89 or 1/1.536
Max Input Power/Torque: 25000 NM
Max Input Speed: 2800 rpm
ZQC2000L
wheeled vehicle transfer case ZQC2000L
Model: ZQC2000L
Ratio (On-road/Off-road): 0.89 or 1/1.536
Max Input Power/Torque: 25000 NM
Max Input Speed: 2800 rpm
ZQC2800
wheeled vehicle transfer case ZQC2800
Model: ZQC2800
Ratio (On-road/Off-road): 1.11/2.37 or 1.47
Max Input Power/Torque: 32000 NM
Max Input Speed: 2800 rpm
Machinery Chassis Transfer Cases
| DuraMac Machinery Chassis Transfer Cases Series Catalogue | ||||||||
Pump Drives
| 800 – 4800 N.m | ||||||||
| 1100 – 4800 N.m | ||||||||
| 2300 – 4800 N.m | ||||||||
Model Max Input Torque/N.m | 0 | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | 7000 |
| DuraMac Pump Drives Catalogue | ||||||||
One Input Two Output ZQC4229
Model: ZQC4229
Ratio: 0.75、0.8225、0.8833、1.132、1.215
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
One Input Two Output ZQC4227
Model: ZQC4226
Ratio: 0.7090、0.7736、0.8431、1.0889、1.186、1.41
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Two Output ZQC4226
Model: ZQC4226
Ratio: 0.5283、0.5385、0.6531、0.7609、0.8837、0.9756
Max Input Power: 500 kW
Max Input Torque: 3000 N.m
One Input Two Output ZQC4225
Model: ZQC4225
Ratio: 0.6552、0.7143、0.7778、1.2857、1.4、1.526
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
One Input Two Output ZQC4224
Model: ZQC4224
Ratio: 0.6552、0.7143、0.7778、1.2857、1.4、1.526
Max Input Power: 400 kW
Max Input Torque: 1500 N.m
One Input Two Output ZQC4223
Model: ZQC4223
Ratio: 0.7142、0.8261、0.9535、1.2105、1.3333、1.4
Max Input Power: 320 kW
Max Input Torque: 1100 N.m
One Input Two Output ZQC4222
Model: ZQC4222
Ratio: 0.5909、0.7073、0.8421、0.9444
Max Input Power: 193 kW
Max Input Torque: 800 N.m
One Input Three Output ZQC4239
Model: ZQC4239
Ratio: 0.75、0.8226、0.9483、1.1321、1.2157、1,4889
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
One Input Three Output ZQC4238
Model: ZQC4238
Ratio: 0.6207、0.6607、0.6786、0.7091、0.7736、0.8431
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Three Output ZQC4237
Model: ZQC4237
Ratio: 0.6607、0.8131、1.0217、1.0889、1.4103
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Three Output ZQC4236
Model: ZQC4236
Ratio: 0.6604、0.7255、0.76、0.7959、0.8723、0.9556
Max Input Power: 650 kW
Max Input Torque: 3000 N.m
One Input Three Output ZQC4235
Model: ZQC4234
Ratio: 0.6572、0.7586、0.8710、1.1481、1.32、1.5217
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
One Input Three Output ZQC4234
Model: ZQC4234
Ratio: 0.6000、0.7778、0.92、1.0426、1.2857
Max Input Power: 400 kW
Max Input Torque: 1500 N.m
One Input Three Output ZQC4233
Model: ZQC4233
Ratio: 0.7143、0.8260、0.9335、1.21、1.4
Max Input Power: 320 kW
Max Input Torque: 1100 N.m
One Input Four Output ZQC4249
Model: ZQC4249
Ratio: 0.7500、0.8833、0.9483、1.1321、1.2157、1.4889
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
One Input Four Output ZQC4247
Model: ZQC4247
Ratio: 0.7091、0.8431、0.9787、1.186、1.2927、1.5135
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Four Output ZQC4245
Model: ZQC4245
Ratio: 0.7576、0.8125、0.9661、1.2308、1.4167
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
Other Transfer Cases
DuraMac Other Transfer Cases Series Catalogue
