Model: ZQC4229
Ratio: 0.75、0.8225、0.8833、1.132、1.215
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
Pump Drives
The pump drive is a specialized power distribution device designed for hydraulic pump drives in construction machinery. Classified by output channels, it includes one-to-two, one-to-three, and one-to-four series, covering multiple models such as ZQC4222-ZQC4249. It features a maximum input power of 900 kW, a maximum input torque of 4800 N.m, and a rated input speed of 1800 rpm-2500 rpm. with gear ratios available in multiple specifications including 0.5283 to 1.526. Its core function is to distribute power to multiple hydraulic pumps, providing stable power to the hydraulic systems of construction machinery such as cranes and pavers. It supports a maximum single-pump power of 210 kW and torque of 460 N.m, meeting the simultaneous operation requirements of multiple hydraulic actuators.
Advantages of Pump Drives
- Low-power design with precise speed ratio and high transmission efficiency.
- Supports one-to-two/three/four outputs, with a maximum single-pump power of 460 kW, compatible with multiple actuators.
- Reliable lubrication and heat dissipation, low noise and temperature rise, suitable for prolonged high-load operations.
- Wide selection range for power, torque, and speed ratio, precisely matching diverse construction machinery requirements.
DuraMac
DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.
Fast Gear
The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.
EV Truck
Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.
DANA Axle
Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.
Datong Gear
The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
| 800 – 4800 N.m | ||||||||
| 1100 – 4800 N.m | ||||||||
| 2300 – 4800 N.m | ||||||||
Model Max Input Torque/N.m | 0 | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | 7000 |
| DuraMac Pump Drives Catalogue | ||||||||
Find Pump Drives by Series
This is the list of all Series of Pump Drives.
One Input Two Output ZQC4227
Model: ZQC4226
Ratio: 0.7090、0.7736、0.8431、1.0889、1.186、1.41
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Two Output ZQC4226
Model: ZQC4226
Ratio: 0.5283、0.5385、0.6531、0.7609、0.8837、0.9756
Max Input Power: 500 kW
Max Input Torque: 3000 N.m
One Input Two Output ZQC4225
Model: ZQC4225
Ratio: 0.6552、0.7143、0.7778、1.2857、1.4、1.526
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
One Input Two Output ZQC4224
Model: ZQC4224
Ratio: 0.6552、0.7143、0.7778、1.2857、1.4、1.526
Max Input Power: 400 kW
Max Input Torque: 1500 N.m
One Input Two Output ZQC4223
Model: ZQC4223
Ratio: 0.7142、0.8261、0.9535、1.2105、1.3333、1.4
Max Input Power: 320 kW
Max Input Torque: 1100 N.m
One Input Two Output ZQC4222
Model: ZQC4222
Ratio: 0.5909、0.7073、0.8421、0.9444
Max Input Power: 193 kW
Max Input Torque: 800 N.m
One Input Three Output ZQC4239
Model: ZQC4239
Ratio: 0.75、0.8226、0.9483、1.1321、1.2157、1,4889
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
One Input Three Output ZQC4238
Model: ZQC4238
Ratio: 0.6207、0.6607、0.6786、0.7091、0.7736、0.8431
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Three Output ZQC4237
Model: ZQC4237
Ratio: 0.6607、0.8131、1.0217、1.0889、1.4103
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Three Output ZQC4236
Model: ZQC4236
Ratio: 0.6604、0.7255、0.76、0.7959、0.8723、0.9556
Max Input Power: 650 kW
Max Input Torque: 3000 N.m
One Input Three Output ZQC4235
Model: ZQC4234
Ratio: 0.6572、0.7586、0.8710、1.1481、1.32、1.5217
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
One Input Three Output ZQC4234
Model: ZQC4234
Ratio: 0.6000、0.7778、0.92、1.0426、1.2857
Max Input Power: 400 kW
Max Input Torque: 1500 N.m
One Input Three Output ZQC4233
Model: ZQC4233
Ratio: 0.7143、0.8260、0.9335、1.21、1.4
Max Input Power: 320 kW
Max Input Torque: 1100 N.m
One Input Four Output ZQC4249
Model: ZQC4249
Ratio: 0.7500、0.8833、0.9483、1.1321、1.2157、1.4889
Max Input Power: 900 kW
Max Input Torque: 4800 N.m
One Input Four Output ZQC4247
Model: ZQC4247
Ratio: 0.7091、0.8431、0.9787、1.186、1.2927、1.5135
Max Input Power: 700 kW
Max Input Torque: 3300 N.m
One Input Four Output ZQC4245
Model: ZQC4245
Ratio: 0.7576、0.8125、0.9661、1.2308、1.4167
Max Input Power: 530 kW
Max Input Torque: 2300 N.m
