Wheeled Vehicle Transfer Cases

The wheeled vehicle transfer case is a core transmission
component specifically engineered for all-wheel-drive wheeled vehicles. Developed based on imported ZF-STEYR technology, it encompasses multiple models including ZQC500, ZQC600, ZQC800 to ZQC2800 models. With maximum input torque ranging from 5000Nm to 32000Nm and peak input speeds reaching 4300rpm, it accommodates wheeled vehicles with diverse power requirements. Its core function is to achieve rational power distribution between front and rear axles, supporting high-range (On-road) and low-range (Off-road) switching to meet dual demands for highway driving and complex off-road conditions. It is primarily applied in military off-road vehicles, desert oil field vehicles, all-terrain cranes, and other wheeled all-wheel-drive vehicles.

Advantages of Wheeled Vehicle Transfer Cases

Maximum input torque up to 32,000 Nm, suitable for high-intensity operations;
Features ZF-STEYR technology with integrated lubrication pump and inter-axle differential for balanced power distribution;
Pneumatic/mechanical shifting with optional external oil cooler for versatile applications;
Multiple models cover diverse requirements, with optional PTO and compatibility with various vehicle interfaces.

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Find Wheeled Vehicle Transfer Cases by Types

This is the list of all Types of Wheeled Vehicle Transfer Cases.

ZQC500

ZQC500

Transfer Case for Wheeled Vehicles ZQC500
Model: ZQC500
Ratio (On-road/Off-road): 0.91/2.08
Max Input Torque: 5000 Nm
Max Input Speed: 4300 rpm

ZQC500

ZQC800

wheeled vehicle transfer case ZQC800
Model: ZQC800
Ratio (On-road/Off-road): 1/1.5
Max Input Power/Torque: 8000 NM
Max Input Speed: 3000 rpm

ZQC500

ZQC1200

wheeled vehicle transfer case ZQC1200
Model: ZQC1200
Ratio (On-road/Off-road): 1/1.75or1.285
Max Input Power/Torque: 12000 NM
Max Input Speed: 3000 rpm

ZQC500

ZQC1600

Transfer Case for Wheeled Vehicles ZQC1600
Model: ZQC1600
Ratio (On-road/Off-road): 0.89/1.536
Max Input Power/Torque: 18000 NM
Max Input Speed: 2800 rpm

ZQC500

ZQC2000

wheeled vehicle transfer case ZQC2000
Model: ZQC2000
Ratio (On-road/Off-road): 0.89 or 1/1.536
Max Input Power/Torque: 25000 NM
Max Input Speed: 2800 rpm

ZQC500

ZQC2000L

wheeled vehicle transfer case ZQC2000L
Model: ZQC2000L
Ratio (On-road/Off-road): 0.89 or 1/1.536
Max Input Power/Torque: 25000 NM
Max Input Speed: 2800 rpm

ZQC500

ZQC2800

wheeled vehicle transfer case ZQC2800
Model: ZQC2800
Ratio (On-road/Off-road): 1.11/2.37 or 1.47
Max Input Power/Torque: 32000 NM
Max Input Speed: 2800 rpm
